• Country
• Germany

• Manufacturer / Brand
• Arcus Elektroakustik GmbH; Berlin

• Year
• 1985 ??

• Category
• Loudspeaker, headphone or earphone

• Radiomuseum.org ID
• 199042

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• No Power needed

• Loudspeaker
• 4 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: HiFi Lautsprecher-Box TM-1000 - Arcus Elektroakustik GmbH;

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 370 x 1155 x 458 mm / 14.6 x 45.5 x 18 inch

• Notes
• 4-Wege Transmissionline, Standlautsprecher, Tieftöner: 1x 305mm (Konus), Tiefmitteltöner: 1x 270mm (Konus), Mitteltöner: 1x 100mm (Konus), Hochtöner: 5x 25mm (Kalotte), Belastbarkeit (Nenn-/Musikb.): 130/250 Watt Frequenzgang: 18 - 21.000 Hz (±3 dB), Übergangsbereiche: 125 / 425 / 2.800 Hz, Impedanz: 8 Ohm, Farben: 18 Edelholz- und Farbversionen, Acrylgehäuse als Sonderanfertigung

• Source of data
• - - Data from my own collection

• Mentioned in
• - - Manufacturers Literature
