PX2

Argal Radio; Pistoia

Data
Forum
Pictures
Collections

  • Year
  • 1951 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 354584

 Technical Specifications

  • Number of Tubes
  • 6
  • Main principle
  • Superheterodyne (common); ZF/IF 470 kHz
  • Wave bands
  • Broadcast plus more than 2 Short Wave bands.
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 125; 140; 160; 220; 280 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: PX2 - Argal Radio; Pistoia
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 660 x 380 x 240 mm / 26 x 15 x 9.4 inch
  • Notes

  • Medie Frequenze della Gino Corti (MI); Elettrolitici Ducati (BO); Condensatori carta Creas (MI); Altoparlante Fonomeccanica (To) con cartellino collaudo 19/Novembre/1951; Scala parlante e relativa struttura meccanica dei Fratelli D'Andrea (MI); Trasformatore Alimentazione autocostruito;

  • Author
  • Model page created by Remo Del Cortona. See "Data change" for further contributors.
