Aristona Pionnier (Pionier) V6A
NSF (Nederlandsche Seintoestellen Fabriek); Leuven
- Country
- Belgium
- Manufacturer / Brand
- NSF (Nederlandsche Seintoestellen Fabriek); Leuven
- Year
- 1937 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 118896
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 128 kHz; 2 AF stage(s)
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 145; 200; 220; 245 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 20 cm = 7.9 inch
- Material
- Bakelite case
- from Radiomuseum.org
- Model: Aristona Pionnier V6A - NSF Nederlandsche
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 420 x 330 x 150 mm / 16.5 x 13 x 5.9 inch
- Notes
- License SBR.
- Net weight (2.2 lb = 1 kg)
- 11 kg / 24 lb 3.7 oz (24.229 lb)
- Mentioned in
- NSF-Koerier, December 1941
