SA3003A /00G /00M
Aristona (B); Brüssel
- Country
- Belgium
- Manufacturer / Brand
- Aristona (B); Brüssel
- Year
- 1959 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 335100
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common); ZF/IF 452 kHz
- Wave bands
- Broadcast, Long Wave and 2 x Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 90; 110; 127; 145; 190; 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: SA3003A /00G /00M - Aristona B; Brüssel
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 356 x 214 x 174 mm / 14 x 8.4 x 6.9 inch
- Author
- Model page created by Miguel Secundino. See "Data change" for further contributors.
- Other Models
-
Here you find 11 models, 11 with images and 3 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Aristona (B); Brüssel
