• Country
• Finland

• Manufacturer / Brand
• Asa Radio Oy; Turku

• Year
• 1961 ?

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 216846

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 21

• Valves / Tubes
• PCF82 PCC88 EF80 EF80 EF80 EF80 PCF82 ECH81 EBF89 PCL84 PCF80 PCF82 PCF82 ECC82 PCL85 PCL86 PCF80 PY88 PL36 DY87

• Main principle
• Superheterodyne (common)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• 2 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: Asavisio 2011/59B - Asa Radio Oy; Turku

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 610 x 530 x 420 mm / 24 x 20.9 x 16.5 inch

• Author
• Model page created by Timo Rantasaari. See "Data change" for further contributors.
