• Country
• Spain

• Manufacturer / Brand
• Askar, Ascar; Irún

• Year
• 1958

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 81162

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• HCH81 HF93 HBC90 HL94 HY90

• Main principle
• Superheterodyne (common); ZF/IF 470 kHz; 2 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast, Short Wave(s) and Police.

• Power type and voltage
• AC/DC-set / 110, 127 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 613-U - Askar, Ascar; Irún

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 410 x 260 x 180 mm / 16.1 x 10.2 x 7.1 inch

• Notes
• Onda Media de: 185 a 580 m. Onda Pesquera de: 59 a 187 m. Onda Corta de: 16,4 a 51,5 m.

• Net weight (2.2 lb = 1 kg)
• 7 kg / 15 lb 6.7 oz (15.419 lb)

• Price in first year of sale
• 3,249.00 ESP

• Source of data
• -- Original-techn. papers.

• Mentioned in
• -- Original-techn. papers.

• Literature/Schematics (1)
• Anuncio La Vanguardia Española 26 Octubre 1958

• Author
• Model page created by Juan Antonio Pardo-Alonso. See "Data change" for further contributors.
