711-U
Askar, Ascar; Irún
- Country
- Spain
- Manufacturer / Brand
- Askar, Ascar; Irún
- Year
- 1960
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 175749
Anuncio La Vanguardia Española enero 1960
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast and Short Wave (SW).
- Power type and voltage
- AC/DC-set / 125 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Bakelite case
- from Radiomuseum.org
- Model: 711-U - Askar, Ascar; Irún
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Notes
-
Gama de cinco colores. Precio final a falta de sumar Impuesto de Lujo
The original tubes are difficult to find. Instead here are the equivalent ones:
12AJ7; 12BA6; 12AT6; 30A5; 35W4
- Price in first year of sale
- 1,670.00 ESP
- Literature/Schematics (1)
- Anuncio La Vanguardia Española 24 Diciembre 1959
- Author
- Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
- Other Models
-
Here you find 127 models, 121 with images and 35 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
