• Country
• Spain

• Manufacturer / Brand
• Askar, Ascar; Irún

• Year
• 1965

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 192505

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 6

• Semiconductors
• AF115 AF115 AF115 AC126 AC128 AC128 OA79 OA79

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast and Short Wave (SW).

• Power type and voltage
• Batteries / addl. power jack / 6 x 1,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: AE-1248-T - Askar, Ascar; Irún

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 358 x 184 x 125 mm / 14.1 x 7.2 x 4.9 inch

• Notes

• Igual a Philips B2E48T

• Source of data
• - - Data from my own collection

• Author
• Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
