- Country
- Germany
- Manufacturer / Brand
- Assmann, W., GmbH; Bad Homburg
- Year
- 1980 ?
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 226280
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 33
- Semiconductors
- BC548 BC549 BC558 BD438 J112 CD4001 CD4011 CD4016 CD4044 CD4049 CD4071 CD4081 BA313 LM386 LM3909 TAA761 TBA820
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Special Tape or Cassette-Format
- Power type and voltage
- Alternating Current supply (AC) / 100-127; 200-250; 220-270 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 cm = 2.4 inch
- Power out
- 0.4 W (unknown quality)
- Material
- Special material, described in the notes.
- from Radiomuseum.org
- Model: M500 - Assmann, W., GmbH; Bad Homburg
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 270 x 60 x 220 mm / 10.6 x 2.4 x 8.7 inch
- Notes
-
Das M500 dient zur Aufnahme und Wiedergabe von Diktaten oder Konferenzen auf Minikassette. Die Wiedergabe kann auch durch jedes beliebige andere Assmann -Minikassettengerät erfolgen. Wesentliche Eigenschaften sind: schneller Vor-und Rücklauf, variable Wiedergabegeschwindigkeit, Bandtransport durch magnetlosen Friktionsantrieb, mechanische Laufzeitskala, Stromversorgung durch Steckernetzteile NA40_41 oder 42, Indexeinrichtung, Leseeinrichtung für aufgezeichnete Indexmarkierungen. Das Gehäuse besteht aus Metall und Kunststoff.
- Net weight (2.2 lb = 1 kg)
- 1.250 kg / 2 lb 12.1 oz (2.753 lb)
- Source of data
- - - Manufacturers Literature
