- Country
- Australia
- Manufacturer / Brand
- Astor (brand), Radio Corporation Pty., Ltd.; Melbourne
- Year
- 1957
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 234359
-
- alternative name: Radio Corp.of Australia
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 21
- Valves / Tubes
- 6CW7 6BL8 6BX6 6BX6 6BX6 6BX6 6BL8 6BX6 6BX6 6BM8 6BL8 6BL8 12AU7 6BM8 6BL8 6CM5 6R3 1S2 6N3 6N3 MW43-64
- Number of Transistors
- Main principle
- Superhet with RF-stage; 2 AF stage(s)
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 240 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 inch = 15.2 cm
- Material
- Metal case
- from Radiomuseum.org
- Model: DSJ series B - Astor brand, Radio Corporation
- Shape
- Tablemodel, with any shape - general.
- Notes
-
43 cm television receiver tunes the 10 then standard Australian VHF channels.
Alternative CRT types were used: A43-64, MW43-69 and 17BP4B.Cabinet colour styling: Nigger Brown, Maroon, Grey & Moss Green.
- Literature/Schematics (1)
- J.R. Publications Television Service Handbook (L.J. Series Vol. 1, 1962 & 1967, Page A47.)
- Literature/Schematics (2)
- - - Manufacturers Literature (Astor Technical Bulletin DSJ Series B-1, 24/10/1957.)
- Author
- Model page created by Stuart Irwin. See "Data change" for further contributors.
