Royal R31C-A/4-Y Ch= Series 4
Astor (brand), Radio Corporation Pty., Ltd.; Melbourne
- Country
- Australia
- Manufacturer / Brand
- Astor (brand), Radio Corporation Pty., Ltd.; Melbourne
- Year
- 1962/1963
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 285968
-
- alternative name: Radio Corp.of Australia
- Number of Tubes
- 14
- Number of Transistors
- Main principle
- Superhet with RF-stage; ZF/IF 36000/30500 kHz; 1 AF stage(s)
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 200; 230; 250 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Royal R31C-A/4-Y Ch= Series 4 - Astor brand, Radio Corporation
- Shape
- Console, Lowboy (legs < 50 %).
- Dimensions (WHD)
- 29 x 33.75 x 16.5 inch / 737 x 857 x 419 mm
- Notes
-
Astor R31C 23" Console
The Astor 23" "Royal" console features include a 13 channel position turret tuner. Press on/off switch combined with the volume control. Separate preset tone control located at rear of set. Cabinet designed by "Gainsborough", finished in "Polyester"
This model is also available as a "Fringemaster". (MINGAY'S PRICE SERVICE)
- Price in first year of sale
- 198.45 AUS £
- Mentioned in
- Mingay's Price Service (Aug 1962 & Feb 1963.)
- Literature/Schematics (1)
- - - Manufacturers Literature (TV Chassis Series 4 Service Data.)
- Literature/Schematics (2)
- J.R. Publications Television Service Handbook (L.J. Series Vol. 1, 1967, Page A66.)
- Author
- Model page created by Stuart Irwin. See "Data change" for further contributors.
