- Country
- Italy
- Manufacturer / Brand
- Atlantic Radio; Borgaro Torinese (Torino)
- Year
- 1967 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 168787
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 14
- Number of Transistors
- 2
- Main principle
- Superheterodyne (common)
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- from Radiomuseum.org
- Model: 160 - Atlantic Radio; Borgaro
- Shape
- Tablemodel, with any shape - general.
- Notes
- Cinescopio 110° 19" o 22".
Sintonizzatore UHF a transistori.
- Circuit diagram reference
- Schemario TV , Il Rostro
- Literature/Schematics (1)
- Schemario TV XXIX Serie Il Rostro
- Author
- Model page created by Eduard Abfalterer. See "Data change" for further contributors.
