• Country
• United States of America (USA)

• Manufacturer / Brand
• Atwater Kent Mfg. Co.; Philadelphia, USA

• Year
• 1926

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 161240

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 7

• Valves / Tubes
• UX201A UX201A UX201A UX201A UX201A or UX200A or UX112 UX201A UX171 or UX112

• Main principle
• TRF without regeneration

• Tuned circuits
• 4 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Storage and/or dry batteries

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Wooden case

• from Radiomuseum.org
• Model: 8270 Model 32 [Pooley 1700-R-2 console] - Atwater Kent Mfg. Co.;

• Shape
• Console with any shape - in general

• Notes
• Pooley 1700-R-2 Chippendale console.
  One dial (primary tuning control knob).

• Source of data
• -- Original prospect or advert

• Author
• Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.
