637 Ch=P637X

Atwater Kent (Brand), C & A Odlin & Co. Ltd; Wellington

Data
Forum
Pictures
Collections

  • Year
  • 1936
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 355012

 Technical Specifications

  • Number of Tubes
  • 7
  • Main principle
  • Superhet with RF-stage; ZF/IF 472.5 kHz; 2 AF stage(s)
  • Tuned circuits
  • 7 AM circuit(s)
  • Wave bands
  • Broadcast, Short Wave(s) and Police.
  • Power type and voltage
  • Alternating Current supply (AC) / 50-60Hz: 230 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 8.5 inch = 21.6 cm
  • Power out
  • 3.3 W (unknown quality)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: 637 Ch=P637X - Atwater Kent Brand, C & A
  • Shape
  • Tablemodel, Tombstone = decorative upright, not cathedral but can have rounded edges.
  • Dimensions (WHD)
  • 14 x 18 x 9 inch / 356 x 457 x 229 mm
  • Notes

  • Atwater Kent 637 Ch=P637X

    The chassis used for this model is also used by model 717 (console).  Models AK 317 and 337 chassis are identical but for the dial arrangement.  Atwater Kent introduced what he called the 'ARROW-LITE' tuning with 'Rainbow Dial' for the 1936 models.  Riders index does list model 637, but points to 317/337 (no particular sheet for 637).

    Made in the USA. See also US version Atwater Kent 637.



  • Price in first year of sale
  • 29.75 NZ £
  • Mentioned in
  • -- Original prospect or advert (King Country Chronicle 8 August 1936 Page 4)
  • Literature/Schematics (1)
  • -- Original prospect or advert (Bay Of Plenty Times 2 May 1936 Page 4)
  • Author
  • Model page created by Brian Stevens. See "Data change" for further contributors.
