84 Grandfather Clock (early)
Atwater Kent Mfg. Co.; Philadelphia, USA
- Country
- United States of America (USA)
- Manufacturer / Brand
- Atwater Kent Mfg. Co.; Philadelphia, USA
- Year
- 1931
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 248968
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common); ZF/IF 130 kHz
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Alternating Current supply (AC) / 110 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 84 Grandfather Clock - Atwater Kent Mfg. Co.;
- Shape
- Grandfather Clock with Radio.
- Notes
-
Grandfather Clock Radio;
Slusser: "Collectors Guide to Antique Radios" 7th edition (2008) gives a collector value of 630 - 840 $. There are different versions. See here a probably later one.
- Source of data
- Collector's Guide to Antique Radios (6th edition)
- Circuit diagram reference
- Rider's Perpetual, Volume 3 = 1933 and before
- Author
- Model page created by Ernst Erb. See "Data change" for further contributors.
