• Country
• United States of America (USA)

• Manufacturer / Brand
• Atwater Kent Mfg. Co.; Philadelphia, USA

• Year
• 1930

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 74759

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 9

• Valves / Tubes
• 24 27 24 24 27 27 45 45 80

• Main principle
• Superheterodyne (common); ZF/IF 130 kHz

• Tuned circuits
• 8 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Alternating Current supply (AC) / 110 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil)

• Material
• Metal case

• from Radiomuseum.org
• Model: H2 Chassis [above 5855201] - Atwater Kent Mfg. Co.;

• Shape
• Chassis only or for «building in»

• Notes
• for Console 72; Photos not here, only at relevant cabinet page !
  IF-section improved by application of band filters.

• Circuit diagram reference
• Rider's Perpetual, Volume 3 = 1933 and before

• Mentioned in
• Rider's Perpetual, Volume 1 = 1931/1934 (1919 to 1931)

• Author
• Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.
