Pree Amplifier Fite F.E. 726
Rafilm Rádió és Filmtechnikai Vállalat; Budapest
- Country
- Hungary
- Manufacturer / Brand
- Rafilm Rádió és Filmtechnikai Vállalat; Budapest
- Year
- 1957 ?
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 233035
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 3
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 110; 220 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Metal case
- from Radiomuseum.org
- Model: Pree Amplifier Fite F.E. 726 - Rafilm Rádió és Filmtechnikai
- Shape
- Tablemodel, high profile (upright - NOT Cathedral nor decorative).
- Notes
-
In: ( 800 Hz) 0,3 MOhm 10 mV. Out: (800 Hz) 200 Ohm 775 mV and 77,5 mV, distortion is less than 1 %. 80-8000 Hz.
- Literature/Schematics (2)
- Filmtechnika, Budapest 1959
- Author
- Model page created by Sándor Selyem-Tóth. See "Data change" for further contributors.
