• Country
• Japan

• Manufacturer / Brand
• Audio-Technica Corporation, Tokio

• Year
• 1980 ?

• Category
• Microphone or Pick-up element

• Radiomuseum.org ID
• 344275

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• No Power needed

• Loudspeaker
• - For headphones or amp.

• Material
• Various materials

• from Radiomuseum.org
• Model: Dual Moving Magnet Phono Cartridge AT71 - Audio-Technica Corporation,

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 10 x 15 x 25 mm / 0.4 x 0.6 x 1 inch

• Notes

• Dual Moving Magnet Phono Cartridge, AT71

  Replacement Stylus Number ARN71 (CN-2411)

  - Output voltage @ 1kHz,5cm/sec.: 6 mV
  - Frequency response: 20 Hz-20 kHz
  - Channel balance: 1.5dB
  - Channel separation @ 1kHz/10kHz: 27B



• Author
• Model page created by Francisco Martins. See "Data change" for further contributors.
