• Year
  • 1950
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 261548
    • alternative name: General Electric Company of Australia Ltd.

 Technical Specifications

  • Number of Tubes
  • 5
  • Main principle
  • Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
  • Tuned circuits
  • 6 AM circuit(s)
  • Wave bands
  • Broadcast and Short Wave (SW).
  • Details
  • Changer (Record changer)
  • Power type and voltage
  • Alternating Current supply (AC) / 200-230; 230-260 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 inch = 30.5 cm
  • Power out
  • 3 W (undistorted)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Hotpoint-Bandmaster H35DGY - Australian General Electric GE
  • Shape
  • Console, Lowboy (legs < 50 %).
  • Dimensions (WHD)
  • 36 x 31 x 16.875 inch / 914 x 787 x 429 mm
  • Notes
  • This radiogram incorporates an "Oak" automatic record changer.

    See also AWA Model 809G.

  • Net weight (2.2 lb = 1 kg)
  • 121 lb (121 lb 0 oz) / 54.934 kg
  • Price in first year of sale
  • 86.50 AUS £
  • Literature/Schematics (1)
  • - - Manufacturers Literature (Hotpoint-Bandmaster Service Data & Technical Information.)
  • Author
  • Model page created by Stuart Irwin. See "Data change" for further contributors.
