- Country
- United States of America (USA)
- Manufacturer / Brand
- Automatic Radio Mfg. Co.; Boston (MA)
- Year
- 1958
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 169124
Sams Photofact Folders reference picture.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Alternating Current supply (AC) / 105 - 120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: CL-100 - Automatic Radio Mfg. Co.;
- Shape
- Tablemodel with Clock ((Alarm-) Clock Radio).
- Notes
-
The Automatic Radio Model CL-100 is an AC operated 5-tube AM receiver with electric clock.
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Date 1-59, Set 426, Folder 5)
- Author
- Model page created by Egon Penker. See "Data change" for further contributors.
