• Country
• Italy

• Manufacturer / Brand
• Autovox SPA; Roma

• Year
• 1967 ?

• Category
• Car Radio, perhaps also + sound player/recorder

• Radiomuseum.org ID
• 193413

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 14

• Semiconductors
• AF117 AF117 AF117 OC75 AC128 OC26 OC26 AF102 AF115 AF116 AF116 AF116 AF116 SFT337

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and FM or UHF.

• Power type and voltage
• Storage Battery for all (e.g. for car radios and amateur radios) / 6-12 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Metal case

• from Radiomuseum.org
• Model: RA171 - Autovox SPA; Roma

• Shape
• Chassis only or for «building in»

• Notes
• Sintonia automatica con possibilità di predisporre cinque stazioni. Dimensioni del ricevitore(senza contenitore FM) 180 x 50 x 185 mm. Dimensioni del contenitore FM 180 x 50 x 30 mm. Peso 2,5 kg. Gamme di ricezione FM 87,5 - 108 MHz, OM 520 - 1610 kHz, OL 150 - 255 kHz.

• External source of data
• Autovox

• Author
• Model page created by Fabio Masetti. See "Data change" for further contributors.
