RA451
Autovox SPA; Roma
- Country
- Italy
- Manufacturer / Brand
- Autovox SPA; Roma
- Year
- 1960 ??
- Category
- Car Radio, perhaps also + sound player/recorder
- Radiomuseum.org ID
- 157659
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superheterodyne (common); ZF/IF 455/10700 kHz
- Wave bands
- Broadcast, Long Wave and FM or UHF.
- Power type and voltage
- Storage and/or dry batteries / 6; 12 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Material
- Metal case
- from Radiomuseum.org
- Model: RA451 - Autovox SPA; Roma
- Shape
- Chassis only or for «building in»
- Dimensions (WHD)
- 105 x 85 x 50 mm / 4.1 x 3.3 x 2 inch
- Notes
- 3 Band Auto Receiver * Circular Dial with luminous pointer * LW- 150:260 Kc/s - MW- 520:1610 Kc/s - FM- 88:108 Kc/s - 6 or 12 V - or + earth. Loudspeaker impedance 3,2 Ohm . Receiver in two units, connected by cable with pin plug, for an easy fitting to dashboard.
- Net weight (2.2 lb = 1 kg)
- 1.4 kg / 3 lb 1.3 oz (3.084 lb)
- Author
- Model page created by J. Virgilio Santos. See "Data change" for further contributors.
