Alba 8001 Ch= PW32
Alba (Brand) Balcombe Ltd., ALBA (Radio & Television) Ltd; London
- Country
- Great Britain (UK)
- Manufacturer / Brand
- Alba (Brand) Balcombe Ltd., ALBA (Radio & Television) Ltd; London
- Year
- 1964
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 103567
-
- Brand: Alba
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 4
- Main principle
- Superheterodyne (common); ZF/IF 470 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast (MW) and Long Wave.
- Details
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 200-250 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Alba 8001 Ch= PW32 - Alba Brand Balcombe Ltd., ALBA
- Shape
- Console, Highboy (legs > 50 %).
- Notes
-
A mono radiogram covering MW and LW, with a four speed autochanger. Released August 1964. Its type PW32 chassis is also fitted into the Alba 8000 radiogram.
- Circuit diagram reference
- Radio and TV Servicing books (R&TVS) book
- Mentioned in
- -- Original-techn. papers.
- Literature/Schematics (1)
- Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (1730 dated 19 November 1965)
- Author
- Model page created by Peter Hoddow. See "Data change" for further contributors.
