- Country
- Great Britain (UK)
- Manufacturer / Brand
- Alba (Brand) Balcombe Ltd., ALBA (Radio & Television) Ltd; London
- Year
- 1948
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 103536
-
- Brand: Alba
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Details
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 200-250 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 inch = 15.2 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: Alba 8531 - Alba Brand Balcombe Ltd., ALBA
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 17.5 x 14.5 x 15.4 inch / 445 x 368 x 391 mm
- Notes
-
Table radiogramophone fitted with 'Plessey' automatic record changer and moving-iron pickup.
- Net weight (2.2 lb = 1 kg)
- 16.4 kg / 36 lb 2 oz (36.123 lb)
- Mentioned in
- -- Original-techn. papers.
- Author
- Model page created by Peter Hoddow. See "Data change" for further contributors.
