CC Recorder 9110
BASF, Badische Anilin- & Soda-Fabrik; Ludwigshafen
- Country
- Germany
- Manufacturer / Brand
- BASF, Badische Anilin- & Soda-Fabrik; Ludwigshafen
- Year
- 1974–1978
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 29415
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 7
- Semiconductors
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Cassette-Recorder or -Player
- Power type and voltage
- Line / Batteries (any type) / 110; 220 / 4 × 1,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 9 cm = 3.5 inch
- Power out
- 0.6 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: CC Recorder 9110 - BASF, Badische Anilin- & Soda-
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 150 x 65 x 265 mm / 5.9 x 2.6 x 10.4 inch
- Notes
- Eingebautes Electret-Mikrofon.
- Net weight (2.2 lb = 1 kg)
- 1.7 kg / 3 lb 11.9 oz (3.744 lb)
- External source of data
- Erb
- Source of data
- Katalog RFP 1974 / Radiokatalog Band 2, Ernst Erb
