• Country
• Germany

• Manufacturer / Brand
• BASF, Badische Anilin- & Soda-Fabrik, EMTEC; Ludwigshafen

• Year
• 1980

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 141563

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• PLL, Phase-locked loop

• Wave bands
• Broadcast (BC) and FM or UHF.

• Details
• Remote Control (with wire or wireless)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: D6310RC - BASF, Badische Anilin- & Soda-

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 426 x 46 x 297 mm / 16.8 x 1.8 x 11.7 inch

• Notes

• AM/FM-Hifi-PLL/Synthesizer-Tuner. 7 doppelt belegbare Stationstasten. Eingebauter Infrarot-Empfänger für Fernbedienungsgeber BASF D 6305 RC TX. Fernbedienbar beim Tuner: Automatische und manuelle Senderwahl, Wellenbereich, Memory und Ein/Aus.

  Passende Verstärker: BASF D-6350 RC oder D-6370 RC.

• Net weight (2.2 lb = 1 kg)
• 4.8 kg / 10 lb 9.2 oz (10.573 lb)

• Source of data
• -- Original prospect or advert

• Author
• Model page created by Franz Scharner. See "Data change" for further contributors.
