HiFi Tuner D 6500

BASF, Badische Anilin- & Soda-Fabrik; Ludwigshafen

Data
Forum
Pictures
Collections

  • Year
  • 1980 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 341661

 Technical Specifications

  • Number of Transistors
  • 24
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Details
  • Hi-Fi equipment
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: HiFi Tuner D 6500 - BASF, Badische Anilin- & Soda-
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 210 x 71 x 174 mm / 8.3 x 2.8 x 6.9 inch
  • Notes

  • BASF HiFi-Mini Komponente Modell BASF D 6500 HiFi-Tuner

    FM 87,5 - 108 MHz, mit AFC
    AM 515 - 1605 kHz
    Verstellbare Ferritantenne an der Rückseite

    4-stelliges LED Display

    Leistungsaufnahme 8 Watt

    4x IC's, 8 LED's



  • Net weight (2.2 lb = 1 kg)
  • 2 kg / 4 lb 6.5 oz (4.405 lb)
  • Mentioned in
  • -- Original prospect or advert (BASF - Die Minimaxis)
  • Author
  • Model page created by Franz Scharner. See "Data change" for further contributors.
