• Country
• Germany

• Manufacturer / Brand
• BASF, Badische Anilin- & Soda-Fabrik, EMTEC; Ludwigshafen

• Year
• 1974/1975

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 29418

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 21

• Semiconductors
• 2SC922 2SC839 2SC900 2SC923 2SB324 2SC945 2SB492 2SD235 OA90 1S953 1S1212 F14A DS133

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Line / Batteries (any type) / 110; 220 / 5 × 1,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 9 cm = 3.5 inch

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Radio-Recorder 9320 - BASF, Badische Anilin- & Soda-

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 320 x 213 x 100 mm / 12.6 x 8.4 x 3.9 inch

• Notes

• Eingebautes Electret-Mikrofon.

   Anschlußmöglichkeit für ext. Mikrofon, Plattenspieler und Tonbandgerät. Zeigerinstrument für Anzeige Rec. Level + Batteriezustand. Zählwerk; Skala beleuchtbar; Teleskopantenne versenkbar.

  Halbleiterliste: Nennung nur einmal pro Typ.

• Net weight (2.2 lb = 1 kg)
• 3.5 kg / 7 lb 11.3 oz (7.709 lb)

• External source of data
• Erb

• Source of data
• Katalog RFP 1974 / Radiokatalog Band 2, Ernst Erb

• Other Models

• Here you find 87 models, 84 with images and 41 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from BASF, Badische Anilin- & Soda-Fabrik, EMTEC; Ludwigshafen
