Audio Amplifier AE782

• Country
• Hungary

• Manufacturer / Brand
• Audio Kino és Hangtechnikai Vállalat, Budapest

• Year
• 1961/1962

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 121680

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 8

• Valves / Tubes
• ECH81 EBF80 ECC83 ECC83 ECC83 EL84 EL84 AZ21

• Main principle
• Superheterodyne (common); ZF/IF 476,3 kHz

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Alternating Current supply (AC) / 110; 127; 150; 220; 250 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Power out
• 12 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: Audio Amplifier AE782 - Audio Kino és Hangtechnikai

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 400 x 330 x 130 mm / 15.7 x 13 x 5.1 inch

• Notes
• Audio power amplifier with BC radio listening-in.

• Net weight (2.2 lb = 1 kg)
• 12.5 kg / 27 lb 8.5 oz (27.533 lb)

• Price in first year of sale
• 5,900.00 HUF

• Literature/Schematics (1)
• Radio es Televizio Vevö Keszülekek, 1960-63

• Literature/Schematics (4)
• Csabai Dániel, Hangerősítő kapcsolások, Budapest 1976.

• Author
• Model page created by Gabriel Toth. See "Data change" for further contributors.
