• Country
• Germany

• Manufacturer / Brand
• Becker, Max Egon, Autoradiowerk Ittersbach bei Pforzheim

• Year
• 1967/1968

• Category
• Car Radio, perhaps also + sound player/recorder

• Radiomuseum.org ID
• 164785

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 12

• Semiconductors
• BF195 BF195 BF185 AF138 AF138 AF138 AF138 AC125 AC126 AC128 AD148 AD148

• Main principle
• Superheterodyne (common); ZF/IF 460/10700 kHz

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Storage Battery for all (e.g. for car radios and amateur radios) / 6; 12 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 5 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: Europa TR LMKU [ab B74940] - Becker, Max Egon,

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 180 x 52 x 150 mm / 7.1 x 2 x 5.9 inch

• Notes
• Empfängerteil (Maße siehe Abmessungen) und Verstärkerteil (180 x 52 x 83 mm). Sendereinstellung durch Variometer.

• Source of data
• -- Original-techn. papers.

• Author
• Model page created by Heribert Jung. See "Data change" for further contributors.
