• Country
• Germany

• Manufacturer / Brand
• Becker, Max Egon, Autoradiowerk Ittersbach bei Pforzheim

• Year
• 1972 ?

• Category
• Car Radio, perhaps also + sound player/recorder

• Radiomuseum.org ID
• 192691

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superhet with RF-stage

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Metal case

• from Radiomuseum.org
• Model: Grand Prix Serie F - Becker, Max Egon,

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 180 x 44 x 190 mm / 7.1 x 1.7 x 7.5 inch

• Notes
• Becker Grand Prix hat 5 mechanische Stationsspeicher (2x UKW, KW, MW, LW) und
  automatischen Sendersuchlauf dessen Empfindlichkeit in 3 Stufen schaltbar ist.
  Klangwaage. Anschluss für Cassette/Tonbandgerät und Automatikantenne.

• Net weight (2.2 lb = 1 kg)
• 1.7 kg / 3 lb 11.9 oz (3.744 lb)

• Author
• Model page created by Museum Roggenhofer. See "Data change" for further contributors.
