• Country
• Germany

• Manufacturer / Brand
• Becker, Max Egon, Autoradiowerk Ittersbach bei Pforzheim

• Year
• 1957–1961

• Category
• Car Radio, perhaps also + sound player/recorder

• Radiomuseum.org ID
• 21436

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes
• ECH81 EBF89 EC92 EL86

• Number of Transistors

• Semiconductors
• C122/6 B250C100

• Main principle
• Superheterodyne (common); ZF/IF 460 kHz

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Storage Battery for all (e.g. for car radios and amateur radios) / 6; 12 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 3 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: Monte Carlo M [ab 500 001] - Becker, Max Egon,

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 181 x 80 x 174 mm / 7.1 x 3.1 x 6.9 inch

• Notes
• Vertreten in USA durch: Becker Autoradio USA Inc.

• Net weight (2.2 lb = 1 kg)
• 3.4 kg / 7 lb 7.8 oz (7.489 lb)

• Price in first year of sale
• 169.00 DM

• External source of data
• Erb

• Source of data
• HdB d.Rdf-& Ferns-GrH 1957/58 / Radiokatalog Band 2, Ernst Erb

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Date 1-63, Set 615, Servicer)
