Monte Carlo TR
Becker, Max Egon, Autoradiowerk Ittersbach bei Pforzheim
- Country
- Germany
- Manufacturer / Brand
- Becker, Max Egon, Autoradiowerk Ittersbach bei Pforzheim
- Year
- 1966/1967
- Category
- Car Radio, perhaps also + sound player/recorder
- Radiomuseum.org ID
- 26605
Bild aus Servicemanual
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 8
- Main principle
- Superheterodyne (common); ZF/IF 460 kHz
- Tuned circuits
- 8 AM circuit(s)
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 6; 12 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 5 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: Monte Carlo TR - Becker, Max Egon,
- Shape
- Chassis only or for «building in»
- Dimensions (WHD)
- 180 x 52 x 148 mm / 7.1 x 2 x 5.8 inch
- Notes
- Halbleiter teilweise mehrfach vorhanden.
Anschluss für Automatikantenne.
- Net weight (2.2 lb = 1 kg)
- 1.6 kg / 3 lb 8.4 oz (3.524 lb)
- Price in first year of sale
- 225.00 DM
- External source of data
- erb
- Source of data
- Handbuch VDRG 1966/1967 / Radiokatalog Band 2, Ernst Erb
