- Country
- Germany
- Manufacturer / Brand
- Becker, Max Egon, Autoradiowerk Ittersbach bei Pforzheim
- Year
- 1958–1963
- Category
- Pre-stage (adaptor for SW/FM/VHF/UHF incl. built-in), Frequency converter
- Radiomuseum.org ID
- 21973
Q: Becker Service
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 2
- Main principle
- RF Converter/Adapter (not voltage converter)
- Tuned circuits
- 2 AM circuit(s)
- Wave bands
- Short Wave (SW only)
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 6; 12 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: Reims U - Becker, Max Egon,
- Dimensions (WHD)
- 140 x 48 x 115 mm / 5.5 x 1.9 x 4.5 inch
- Notes
- Vorsatz für 6 KW-Bänder; für jeden Autoempfänger mit MW-Bereich geeignet.
4 verschiedene Varianten der KW-Bereiche:
Reims U I: 16, 19, 25, 41, 49 m;
Reims U II-IV: Wellenbereiche wie bei Kurzwellenadapter Reims.
- Net weight (2.2 lb = 1 kg)
- 0.7 kg / 1 lb 8.7 oz (1.542 lb)
- Price in first year of sale
- 90.00 DM
- External source of data
- Erb
- Source of data
- HdB d.Rdf-& Ferns-GrH 1958/59 / Radiokatalog Band 2, Ernst Erb
