12 Band Receiver EL-306

Bell & Howell, Wheeling (Illinois)

Data
Forum
Pictures
Collections

  • Year
  • 2008 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 344487
    • Brand: DeVry

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Batteries / addl. power jack / AA: 2 x 1.5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.7 cm = 2.2 inch
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: 12 Band Receiver EL-306 - Bell & Howell, Wheeling
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 130 x 82 x 25 mm / 5.1 x 3.2 x 1 inch
  • Notes

  • Portable FM/(TV1)/(AIR)/MW/SW(1-8) 12 Band Receiver Model Bell&Howell EL-306

    Frequency Range:
    FM 87-108 MHz
    TV1 56-73 MHz
    AIR 108-136 MHz
    MW 525-1600 kHz
    SW1 5.90-6.20 MHz
    SW2 7.10-7.30 MHz
    SW3 9.50-9.90 MHz
    SW4 11.65-12.05 MHz
    SW5 13.60-13.80 MHz
    SW6 15.10-15.60 MHz
    SW7 17.50-17.90 MHz
    SW8 21.45-21.85 MHz

    Earphone Jack

    Telescopic antenna

    External Power Jack - DC 3V


  • Net weight (2.2 lb = 1 kg)
  • 0.170 kg / 0 lb 6 oz (0.374 lb)
  • Author
  • Model page created by Franz Scharner. See "Data change" for further contributors.
