RT-75 Tape Recorder
Bell Sound Systems; Columbus (OH)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Bell Sound Systems; Columbus (OH)
- Year
- 1955/1956
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 123244
SAMS
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Tape Recorder
- Power type and voltage
- Alternating Current supply (AC) / 110-120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Power out
- 3 W (unknown quality)
- from Radiomuseum.org
- Model: RT-75 Tape Recorder - Bell Sound Systems; Columbus
- Dimensions (WHD)
- 14.4 x 15 x 9.2 inch / 366 x 381 x 234 mm
- Notes
- The 3-speed tape recorder and play back unit model RT-75 allows the following speeds: 1 7/8, 3 3/4 and 7 1/2 inches per second tape speed. Dual track. 50 to 9000Hz response at 7 1/2 ips. The monitor for 500 ohms is a wide range unig of 6" x 9" oval.
- Net weight (2.2 lb = 1 kg)
- 15.8 kg / 34 lb 12.8 oz (34.802 lb)
- Mentioned in
- The Radio-Electronic Master Buying Guide, 1956
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (DAt 9-56, set 329, folder 4)
- Author
- Model page created by Emilio Ciardiello. See "Data change" for further contributors.
