• Country
• United States of America (USA)

• Manufacturer / Brand
• Belmont Radio Corp. (B.R.C.); Chicago, Ill.

• Year
• 1934 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 116956

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 58 57 57 2A5 80

• Main principle
• Superhet with RF-stage; ZF/IF 175 kHz

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Alternating Current supply (AC)

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 575 [3 knobs] - Belmont Radio Corp. B.R.C.;

• Shape
• Tablemodel, high profile (upright - NOT Cathedral nor decorative).

• Circuit diagram reference
• Rider's Perpetual, Volume 5 = ca. 1934 and before

• Mentioned in
• Machine Age to Jet Age II (page 74.)

• Literature/Schematics (1)
• Cathedral & Tombstone Radios (page 66.)

• Author
• Model page created by Dirk Taekels. See "Data change" for further contributors.
