- Country
- United States of America (USA)
- Manufacturer / Brand
- Belmont Radio Corp. (B.R.C.); Chicago, Ill.
- Year
- 1950 ??
- Category
- Car Radio, perhaps also + sound player/recorder
- Radiomuseum.org ID
- 116227
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 6 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 5 inch = 12.7 cm
- Material
- Metal case
- from Radiomuseum.org
- Model: 5C12 - Belmont Radio Corp. B.R.C.;
- Shape
- Chassis only or for «building in»
- Notes
- Vibrator for +B
- Circuit diagram reference
- Rider's Perpetual, Volume 18 = 1949 and before
- Author
- Model page created by Egon Penker. See "Data change" for further contributors.
