- Country
- United States of America (USA)
- Manufacturer / Brand
- Bendix Radio Division; Baltimore, MD
- Year
- 1949
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 120664
310087524935/ Pic. just as type proof!
aus SAMS Photofact 9/49 Set 69 Folder 4
Click on the schematic thumbnail to request the schematic as a free document.
- Main principle
- Superheterodyne (common)
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 117 Volt
- Loudspeaker
- Permanent or electro-dynamic (moving coil), system not known yet.
- Material
- Wooden case
- from Radiomuseum.org
- Model: 235 M 1 - Bendix Radio Division;
- Shape
- Tablemodel, high profile (upright - NOT Cathedral nor decorative).
- Notes
- 10" b/w TV with push-button 12 channel US standard VHF tuner, mahogany cabinet with doors.
- Source of data
- -- Collector info (Sammler)
- Author
- Model page created by a member from A. See "Data change" for further contributors.
- Other Models
-
Here you find 440 models, 359 with images and 216 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Bendix Radio Division; Baltimore, MD
Museums
The model 235 M 1 can be seen in the following museums.
