- Country
- United States of America (USA)
- Manufacturer / Brand
- Bendix Radio Division; Baltimore, MD
- Year
- 1950 ?
- Category
- Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)
- Radiomuseum.org ID
- 339584
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 25
- Valves / Tubes
- 6AG5 6CB6 6J6 6CB6 6AU6 6AU6 6AU6 6T8 6AS5 6AU6 6SN7GT 6K6GT 6SN7GT 6BQ6GT 6W4GT 1B3GT 5U4G 16KP4 or 16RP4 or 14CP4 or 14EP4 12AT7 6BE6 6BA6 6AU6 6T8 6K6GT 5Y3GT
- Main principle
- Superhet with RF-stage
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 6001 - Bendix Radio Division;
- Shape
- Console, Lowboy (legs < 50 %).
- Notes
-
Bendix model 6001 is a 17” b/w TV with US standard VHF tuner channels 2 thru 13.
Equipped with VHF tuner AR0T05(type2) and picture tube 16KP4 or 16RP4 or 14CP4 or 14EP4.
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 111 Folder 3 dated 11-50)
- Author
- Model page created by Dirk Taekels. See "Data change" for further contributors.
