- Country
- United States of America (USA)
- Manufacturer / Brand
- Bendix Radio Division; Baltimore, MD
- Year
- 1951/1952
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 184417
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 22
- Valves / Tubes
- 6BC5 6J6 6CB6 6CB6 6CB6 6AH6 6AU6 6AU6 6AU6 6AL5 6AU6 6W6GT 6AU6 6SN7GT 6W6GT 6AL5 6SN7GT 6BQ6GT 6W4GT 1B3GT 5U4G 17BP4A
- Main principle
- Superheterodyne (common); 2 AF stage(s)
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- 110-120 Volt
- Loudspeaker
- Ø 11.75 inch = 29.8 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: C200 - Bendix Radio Division;
- Shape
- Console, Lowboy (legs < 50 %).
- Notes
-
Wellenbereich: VHF, Bildschirmgrösse: 20 Zoll
- Mentioned in
- Bendix Radio Foundation
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Date 5-1951, Set 134, Folder 5)
- Author
- Model page created by Daniel Doll. See "Data change" for further contributors.
