• Country
• Soviet Union

• Manufacturer / Brand
• Irkutsk Radio Works

• Year
• 1961

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 173685

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes
• 6И1П 6К4П 6Н2П 6П14П

• Main principle
• Superheterodyne (common); ZF/IF 465 kHz

• Tuned circuits
• 4 AM circuit(s)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Details
• Record Player (not changer)

• Power type and voltage
• Alternating Current supply (AC) / 127; 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Power out
• 0.5 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Rekord - Рекорд 61M2 - 61М2 - Irkutsk Radio Works

• Shape
• Tablemodel with Push Buttons.

• Notes
• Coverage MW, LW, SW 25-75 m., 33/45/78 rpm/sec turntable. First noval tubes radio set from this manufacturer.

• Mentioned in
• -- Schematic

• Author
• Model page created by Zenonas Langaitis. See "Data change" for further contributors.
