• Country
• United States of America (USA)

• Manufacturer / Brand
• Berlant Associates (Concertone); Los Angeles, CA

• Year
• 1951 ?

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 221601

• • Brand: Concertone

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 8

• Valves / Tubes
• 12AX7 12AX7 12AX7 12AU7 6E5 6AR5 6AR5 5Y3GT

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Tape Recorder

• Power type and voltage
• Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: Concertone 401 - Berlant Associates Concertone;

• Shape
• Chassis only or for «building in»

• Notes

• The Concertone model 401 magnetic tape recorder consist of a cast aluminum plate on which are mounted the drive mechanism, power supply, and amplifier chassis.The mechanism is designed to record on standard 5" and 7" reels, or the professional NAB 10-1/2" reel using the #801 reel adaptor, at the speed of 7-1/2" or 15" per second.

• Price in first year of sale
• 295.00 USD

• Source of data
• - - Manufacturers Literature

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Set 155, folder 4, dated 1-52)

• Author
• Model page created by a member from A. See "Data change" for further contributors.
