Mark 30
Bettor, Industrias; Barcelona
- Country
- Spain
- Manufacturer / Brand
- Bettor, Industrias; Barcelona
- Year
- 1963 ?
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 256459
- Number of Tubes
- 1
- Valves / Tubes
- PCL86
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Rec.Player+Audio.Amp+LS
- Power type and voltage
- Alternating Current supply (AC) / 125; 150; 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Mark 30 - Bettor, Industrias; Barcelona
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 350 x 180 x 350 mm / 13.8 x 7.1 x 13.8 inch
- Notes
-
- Tocadiscos Bettor con amplificador
- Input Tape / Tuner
- Controls for Volume, Treble and Bass
- Record player chassis: Dual 300A.
- Velocidades: 16/ 33/ 45/ 78.
- Net weight (2.2 lb = 1 kg)
- 8 kg / 17 lb 9.9 oz (17.621 lb)
- Author
- Model page created by Julián Muñoz Lorenzo. See "Data change" for further contributors.
