Antenna Tester AT-800

Bird Technologies, Bird Electronic Corp., Bird Engineering Co.; Cleveland (OH)

Data
Forum
Pictures
Collections

  • Year
  • 1995
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 355243

 Technical Specifications

  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Power type and voltage
  • Storage and/or dry batteries / 11-16 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Antenna Tester AT-800 - Bird Technologies, Bird
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 118 x 42 x 204 mm / 4.6 x 1.7 x 8 inch
  • Notes

  • Medidor de antenas , VSWR y medidor de intensidad de campo.

    Rango de 806-960 Mz.

  • Net weight (2.2 lb = 1 kg)
  • 0.8 kg / 1 lb 12.2 oz (1.762 lb)
  • Literature/Schematics (1)
  • - - Manufacturers Literature (Operator Manual AT-800 Antenna Tester, Bird, 1995, P/N 920-AT800-1 Rev. D.)
