Transistor and Crystal Diode Tester 960
B&K (Precision), Dynascan Corp., Cobra Electronics; Chicago, IL and Yorba Linda, CA
- Country
- United States of America (USA)
- Manufacturer / Brand
- B&K (Precision), Dynascan Corp., Cobra Electronics; Chicago, IL and Yorba Linda, CA
- Year
- 1958 ?
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 329388
-
- alternative name: B&K Manufacturing Company
Click on the schematic thumbnail to request the schematic as a free document.
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 110 - 125 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Leather / canvas / plastic - over other material
- from Radiomuseum.org
- Model: Transistor and Crystal Diode Tester 960 - B&K Precision, Dynascan Corp.,
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 18 x 6.75 x 11 inch / 457 x 171 x 279 mm
- Notes
-
See later model Transistor Radio Analyst 960.
- Net weight (2.2 lb = 1 kg)
- 9.5 lb (9 lb 8 oz) / 4.313 kg
| Crystal Diodes Test Data | 4850 KB | |
| Supplementary Data for Transistors | 3832 KB |
- Documents regarding this model
- Author
- Model page created by David Erali. See "Data change" for further contributors.
