Operatic Mignon A6B
Operatic (brand), Bland Radio Pty. Ltd.: Adelaide SA
- Country
- Australia
- Manufacturer / Brand
- Operatic (brand), Bland Radio Pty. Ltd.: Adelaide SA
- Year
- 1953
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 193899
-
- Brand: Operatic
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 8 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Direct Current supply (DC) / 32 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- from Radiomuseum.org
- Model: Operatic Mignon A6B - Operatic brand, Bland Radio
- Circuit diagram reference
- Australian Official Radio Service Manual Vol. XII
- Author
- Model page created by Stuart Irwin. See "Data change" for further contributors.
