• Country
• Germany

• Manufacturer / Brand
• Blaupunkt (Ideal), Berlin, später Hildesheim

• Year
• 1957 ?

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 104799

• • alternative name: Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
  • Brand: Rotstern

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 18

• Valves / Tubes
• PCC88 PCF82 EF80 PCL84 ECC82 ECH81 PCL82 ECC81 PL36 PY83 EY86 PABC80 PL82 AW43-80

• Main principle
• Superheterodyne (common)

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• AC/DC-set / 220 Volt

• Loudspeaker
• 4 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: Arkona 17 7446 - Blaupunkt Ideal, Berlin,

• Notes
• Röhren teilweise mehrfach vorhanden. Band I und III.

• Literature/Schematics (1)
• Lange, Schaltungen der Funkindustrie

• Author
• Model page created by Walter Wiesmüller † May 2012. See "Data change" for further contributors.
