Bus-Mikrofonverstärker Kassel 2430 7.607.374 ab 170001
Blaupunkt (Ideal), Berlin, später Hildesheim
- Country
- Germany
- Manufacturer / Brand
- Blaupunkt (Ideal), Berlin, später Hildesheim
- Year
- 1979 ??
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 146186
-
- alternative name: Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
- Brand: Rotstern
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 4
- Semiconductors
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 24 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 30 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: Bus-Mikrofonverstärker Kassel 2430 7.607.374 [ab 170001] - Blaupunkt Ideal, Berlin,
- Shape
- Chassis only or for «building in»
- Dimensions (WHD)
- 160 x 30 x 95 mm / 6.3 x 1.2 x 3.7 inch
- Notes
- 2 IC; Lautsprecherausgang 4 oder 12 Ohm wählbar. Mikrofoneingang 200 Ohm, 0,46 mV
- Mentioned in
- -- Original-techn. papers.
- Author
- Model page created by Josef Pilz. See "Data change" for further contributors.
