• Country
• Germany

• Manufacturer / Brand
• Blaupunkt (Ideal), Berlin, später Hildesheim

• Year
• 1977/1978

• Category
• Loudspeaker, headphone or earphone

• Radiomuseum.org ID
• 195415

• • alternative name: Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
  • Brand: Rotstern

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Loudspeaker
• 3 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: Digita L70 7627970 - Blaupunkt Ideal, Berlin,

• Dimensions (WHD)
• 240 x 410 x 200 mm / 9.4 x 16.1 x 7.9 inch

• Notes
• HiFi Lautsprecherbox für Digita 500 Serie, 3 Wege 1 x Tiefton 195mm, 1 x Mitteltonkalotte 50mm und 1 x Hochtonkalotte 25mm, Frequenzbereich 35 - 22000 Hz, 50/70 Watt, Volumen 19,6 Liter.

• Source of data
• -- Original prospect or advert

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Richard Winter. See "Data change" for further contributors.
